| CPU |
AMD Ryzen™ 5 2600 6-core 3.4 GHz processor, Turbo Core 3.9 GHz |
| CPU Architecture |
64-bit x86 |
| Encryption Engine |
(AES-NI) |
| System Memory |
8 GB UDIMM DDR4 (2 x 4GB) |
| Maximum Memory |
64 GB (4 x 16 GB) |
| Memory Slot |
4 x DDR4 long DIMM |
| Flash Memory |
5GB (Dual boot OS protection) |
| Drive Bay |
12 x 3.5-inch |
| Drive Compatibility |
3.5-inch SATA hard disk drives | 2.5-inch SATA hard disk drives | 2.5-inch SATA solid state drives |
| Gigabit Ethernet Port (RJ45) |
2 |
| 10 Gigabit Ethernet Port |
2 x 10GbE SFP+ SmartNIC port |
| PCIe Slot |
4 Slot 1: Gen3 x4 | Slot 2: Gen3 x8 or Gen3 x4* | Slot 3: Gen3 x8 or Gen3 x4** | Slot 4: Gen3 x4 |
| USB 3.0 port |
4 |
| USB 3.1 Gen 2 (10Gbps) Port |
1 x Type-C USB 3.1 Gen2 5V/3A 10Gbps 1 x Type-A USB 3.1 Gen2 5V/1A 10Gbps |
| Form Factor |
2U Rackmount |
| LED Indicators |
HDD 1-12, Status, LAN, storage expansion port status |
| Buttons |
Power, Reset |
| Dimensions (HxWxD) |
88.3 x 482 x 562 mm |
| Weight (Net) |
13.73 kg |
| Weight (Gross) |
16 kg |
| Power Supply Unit |
300W (x2), 100-240V |
| Power Consumption: Operating Mode, Typical |
106.66 W |
| Fan |
System: 2 x 7cm fan (12V DC) |
| Sound Level |
37.2 db(A) |
| System Warning |
Buzzer |
| Warranty |
2 thn |
