| Spesifikasi | |
|---|---|
| Output power capacity | 540Watts / 900VA |
| Bypass | Built-in Bypass |
| Max Configurable Power (Watts) | 540Watts / 900VA |
| Output Frequency (sync to mains) | 50/60Hz +/- 3 Hz |
| Nominal Output Voltage | 230V |
| Transfer Time | 8ms typical : 10 ms maximum |
| Waveform type | Stepped approximation to a sinewave |
| Output Frequency (not synced) | 50/60 Hz +/-1 Hz |
| Topology | Line Interactive |
| Load Crest Factor | 3;1 |
| Nominal Input Voltage | 230V |
| Maximum Input Current | 8.0A |
| Input frequency | 50/60 Hz +/- 3 Hz (auto sensing) |
| Input voltage adjustable range for mains operation | 156 - 300V |
| Input Connections | IEC-320 C14 |
| Number of Power Cords | 1 |
| Input voltage range for main operations | 176 - 294V |
| Battery type | Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof |
| Interface Port(s) | Optional Simple Signalling RS232 cable, USB |
| Typical recharge time | 8hour(s) |
| Data Line Protection | Analog phone line for phone/fax/modem/DSL (RJ-11 connector), Network line - 10/100/1000 Base-T Ethernet (RJ-45 connector) |
| Audible Alarm | Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm |
| Filtering | Full time multi-pole noise filtering :10% of IEEE surge let-thgouh : zero clamping response time: instantaneous |
| Control panel | Multi-function LCD status and control console |
| Surge energy rating | 613Joules |
| Garansi | 12 Bulan dari Distributor Resmi di Indonesia |
