| Spesifikasi | |
|---|---|
| IP video input | 32-ch; Up to 12 MP resolution |
| Two-way audio | 1-ch, RCA (2.0 Vp-p, 1 k Ω) |
| Incoming bandwidth | 320 Mbps |
| Outgoing bandwidth | 256 Mbps, or 200 Mbps (when RAID is enabled) |
| Remote connection | 128 |
| Recording resolution | 12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF /2CIF/CIF/QCIF |
| CVBS output (Optional) | 1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480 |
| VGA1 /HDMI1 output resolution | HDMI1: 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080p/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz; VGA1: 2K (2560 × 1440)/60Hz, 1920 × 1080p/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| VGA2 /HDMI2 output resolution | 1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| Audio output | 2-ch, RCA (2.0Vp-p, 1 KΩ) |
| Decoding format | H.265/H.265+/H.264/H.264+/MPEG4 |
| Liveview/Playback resolution | 12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF /2CIF/CIF/QCIF |
| Synchronous playback | 16-ch |
| Capability | 2-ch @ 12 MP (20fps) / 4-ch @ 8 MP (25fps) / 8-ch @ 4MP (30fps) / 16-ch @ 1080p (30fps) |
| Network protocols | TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS |
| SATA | 8 SATA interfaces |
| eSATA | 1 eSATA interface |
| Capacity | Up to 10TB capacity for each HDD |
| Array type | RAID0, RAID1, RAID5, RAID6, RAID10 |
| Number of arrays | 4 |
| Network interface | 2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface |
| Serial interface | RS-232; RS-485; Keyboard |
| USB interface | Front panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0 |
| Alarm in/out | 16/4 |
| Power supply | 100 to 240 VAC, 50 to 60 Hz |
| Max. Power | 200 W |
| Consumption (without hard disk) | ≤ 30 W |
| Working temperature | -10 to +55º C (+14 to +131º F) |
| Working humidity | 10 to 90 % |
| Chassis | 19-inch rack-mounted 2U chassis |
| Dimensions(W × D × H) | 445 × 470 ×90 mm (17.5"× 18.5" × 3.5") |
| Weight (without hard disk) | ≤ 10 kg (22 lb) |
| Warranty | 1 Year |
