| Scanner Type |
A3 flatbed colour image scanner |
| Sensor Type |
4-line colour CCD |
| Optical Resolution |
600 x 600 dpi |
| Output Resolution |
50 dpi - 4,800 dpi (1 dpi increments), 7,200 dpi and 9,600 dpi |
| Scanner Bit Depth |
Colour : 48-bit input, 24-bit output, Grayscale : 16-bit input, 8-bit output, Black & White : 16-bit input, 1-bit output |
| Max Document Size |
297 x 420mm |
| Output File Formats |
JPEG, TIFF, Multi-TIFF, PDF, BMPDocument Capture Pro (Win): JPEG, BMP, PDF, Searchable PDF, TIFF, Multi-TIFF, PNG, DOCX, XLSX, PPTX |
| Scan Speed |
Flatbed (Black / Colour) : 300 dpi: 4.0 sec / 4.0 sec, 600 dpi: 10 sec / 10 sec; ADF Monochrome (Simplex / Duplex) : 200 dpi: 70 ppm / 140 ipm, 300 dpi: 70 ppm / 140 ipm, 600 dpi: 25 ppm / 50 ipm : ADF Colour (Simplex / Duplex) : 200 dpi: 70 ppm / 140 ipm |
| ADF Capacity |
200 sheets |
| Automatic Duplex Scanning |
Yes |
| Daily Duty Cycle |
up to 8,000 sheets / day |
| Multi-feed Detection |
Ultrasonic Sensor |
| Connectivity Standard |
USB 2.0 |
| Network |
Ethernet (with optional Network Interface Panel) |
| Supported OS |
Windows XP SP3 / Vista / 7 / 8 / 8.1 / 10 / Server 2003 / 2008 / 2012 / 2016 / 2019Mac OS X 10.6.8 or later |
| Dimensions (W x D x H) |
640 x 552 x 289 mm |
| Weight |
26.9kg |
| Warranty |
3 Years |
