Spesifikasi | |
---|---|
Scanner Type | A4 flatbed colour image scanner |
Sensor Type | 4-line colour CCD |
Light Source | White LED |
Optical Resolution | 1,200 dpi x 1,200 dpi |
Output Resolution | 50 dpi - 4,800 dpi (1 dpi increments), 7,200 dpi and 9,600 dpi |
Scanner Bit Depth | Colour : 48-bit input, 24-bit output, Grayscale : 16-bit input, 8-bit output, Black & White : 16-bit input, 1-bit output |
Max Document Size | 216 x 297mm |
Output File Formats | JPEG, TIFF, Multi-TIFF, PDF, BMPDocument Capture Pro (Win): JPEG, BMP, PDF, Searchable PDF, TIFF, Multi-TIFF, PNG, DOCX, XLSX, PPTX |
Scan Speed | Flatbed (Black / Colour) : 300 dpi: 8.0 sec / 8.0 sec, 600 dpi: 22 sec / 22 sec; ADF Monochrome (Simplex / Duplex) : 200 dpi: 25ppm / 50ipm, 300 dpi: 25ppm / 50ipm, 600 dpi: 6.0ppm / 12ipm; ADF Colour (Simplex / Duplex) : 200 dpi: 25ppm / 50ipm, 600 dpi: 4.0ppm / 8.0ipm |
Scanner Type | A4 sheet-fed , one-pass duplex scanner |
Optical Sensor | 4-line colour CCD |
Optical Resolution | 600 dpi x 600 dpi |
Output Resolution | 50 – 600 dpi (in 1 dpi increments) |
Max Document Size | 215.9mm x 1,016mm |
ADF Capacity | 100 sheets |
Automatic Duplex Scanning | Yes |
Daily Duty Cycle | up to 3,000 pages / day |
Multi-feed Detection | Ultrasonic sensor |
Connectivity Standard | USB 2.0 |
Network | Ethernet (with optional Network Interface Panel) |
Supported OS | Windows XP SP3 / Vista / 7 / 8 / 8.1 / 10 / Server 2003 / 2008 / 2012 / 2016 / 2019, Mac OS X 10.6.8 or later |
Dimensions (W x D x H) | 495 x 360 x 217 mm |
Weight | 9.8kg |
Warranty | 3 Years |
