| Spesifikasi | |
|---|---|
| Panel Size | 75inch |
| Type/Tech | TFT LCD Module with DLED Backlight |
| Colors | 1.07B Colors (10bit) |
| Brightness | 350 nits (typ.) 300 nits (min.) |
| Contras Ratio | 1200;1 Typ. |
| Response Time | 9ms |
| Backlight Life | 30,000 Hours (Min) |
| Surface Treatment | Anti-Glare |
| Bezel | Slim |
| Orientation | Landscape |
| Touch Type/Tech | IR Recognition |
| Touch Point | 20 Points Touch, 10 Points Writing |
| Input Connection | HDMI 2.0 x3 (3840x2160 @60Hz) | RGB/VGA x1 | Audio x1 (PC Audio In) | CVBS x1 | RS232 1x | OPS x1 PC Slot (Proprietary) |
| Output Connection | HDMI x1 | Audio x1 (Earphone out) | SPDIF 1 (Optical) | RS232 x1 |
| LAN | RJ45 x1 |
| USB Type A | USB 2.0 x4 (Including 2 USB Port in from t) & USB 3.0 x2 (Including 1 USB Prot in from t) |
| USB Type B | x2 for touch |
| Compability RGB PC/HDMI PC | Refer to timing table |
| Compability CVBS | 480i |
| Compability HDMI | 3840x2160 |
| Embedded OS | Android 7 |
| USB Support File Format | Picture - BMP, JPEG, PNG | Video - Codec; MPEG1, MPEG2, MPEG2-PG, MPEG4, MKV | Audio - Codec; AAC, HEAAC, MPEG1, MPEG2 | Container AAC, M4A, MP3 |
| Basic Annotation Software | myViewBoard |
| Pro Annotation Software | myViewBoard for windows (Embedded in Windows Slot-in PC) |
| Wireless Presentation with Touch Feedback; Viewboard Cast | Yes |
| Zoom | Yes |
| ViewSonic Launcher | Embedded |
| Special Feature | All-in-One USB port (Combine Windows/Android USB port; no need to distinguish them anymore) | Front InchSmartPort USBInch to all channels |
| Simple LAN Sharing between IFP and slot-in device | Yes |
| Power Voltage | 100-240VAC +/- 10% Wide Range |
| Power Consumption | 81W (Typ.) < 0.5 W (InchOffInch) |
| Ergonimics | Wall Mount (VESA) 400 x 200 |
| Package Contents | Power Cable (3 Meters) x4 | Remote Control | USB Cable (5 Meters) | AV Cable | Touching Pen x2 | Quick Start Guide | RS232 Adapter | Clamp x5 | Plate | Screw x8 | HDMI Cable |
