| Scanner Type |
Sheet-fed color document scanner |
| Image Sensor Type |
CCD |
| Resolution |
600 dpi |
| Light Source |
LED |
| Scanning Area |
8.5†x65†(216 x 1651mm) |
| Scanning Speed |
50 ppm/ 100 ipm @200 dpi, A4, Color, 50 ppm/ 100 ipm @300 dpi, A4, Gray/ B&W(Scanning speed may vary depending on your computer spec, operating system, and software.) |
| Feed Detection |
Ultrasonic Double Feed Detection |
| Feeder Capacity |
Paper: Up to 100 sheets (16 ~ 18 lbs / 60 ~ 67.5 g/m²), Card: Up to 2 cards (1.3 mm / 0.05Inch) |
| Paper Size |
Max: 8.5Inch x 65Inch(216 x 1651mm), Min: 2.75Inch x 3.149Inch ( 70 x 80 mm) |
| Paper Weight (Thickness) |
8 ~ 32 lbs (30 ~120 g/m²) |
| Card Thickness |
Up to 1.3 mm (0.05Inch) |
| Connectivity |
Hi-Speed USB (USB 2.0) |
| Drivers |
TWAIN |
| Smart-Touch Buttons |
3 buttons, 5 modes |
| Scanable Media Types |
Reflective (Paper, Name card, Plastic card) |
| Supported File Types |
TIF, BMP, PCX, PDF, DCX, JPG |
| OS Support |
Windows XP/ Vista/ Windows 7/ 8 (ScanWizard DI) ; Mac OS X 10.6 or later (ScanPotter) |
| Dimensions (L x W x H) |
7.08Inch x 12.60Inch x 7.87Inch / 180 x 320 x 200mm |
| Weight |
9.26lbs (4.2kg) |
| Certifications |
CE, FCC, BSMI, C-TICK, CCC, VCCI, WEEE, ENERGY STAR® |
| Power Source |
AC100V~240V |
| Power Consumption |
22.5 Watts (Operation) ; 3.88Watts (Sleep) ; 0.4Watts (Off) |
| System Requirements PC |
CD-ROM/DVD-ROM drive (for installing software), Color display with 24-bit color output capability, CPU: Intel Core2 Duo 2.1 GHz Processor or higher (recommended), RAM: 1 GB RAM or more (2 GB is recommended), HDD: SATA2/SATA3 7200 RPM or SSD H.D, USB: 2.0 or above, Microsoft Window |
| System Requirements MAC |
CD-ROM/DVD-ROM drive (for installing software), Color display with 24-bit color output capability, 1 GB RAM or more (2 GB is recommended), Mac computer (Intel CPU) with built-in USB port, Mac OS X 10.6 or later |
| Warranty |
1 Years Limited |
