| Spesifikasi | |
|---|---|
| Form factor | Fixed platform, Virtual Chassis configuration consisting of up to four switches, Junos Fusion Enterprise Satellite device |
| Dimensions (W x H x D) | EX2300-24T/24P/48T: 17.4 x 1.75 x 10.2 in (44.19 x 4.45 x 25.9 cm), 1 rack unit |
| Backplane speed | 80 Gbps |
| Data rate | EX2300-24P/24T: 128 Gbps |
| Throughput | EX2300-24P/24T: 95 Mpps (wire speed) |
| 10/100/1000BASE-T port densities | 12 |
| 10GBASE-X port densities | 2 |
| 40GBASE quad small form-factor pluggable plus transceiver (QSFP+) port densities | N/A |
| 100GBASE C form-factor pluggable transceiver (CFP) port densities | N/A |
| Resiliency | Integrated power supply and fans |
| Operating system | Junos OS |
| Traffic monitoring | sFlow |
| Quality-of-service (QoS) queues/port | 8 |
| MAC addresses | 16 |
| Jumbo frames | 9216 bytes |
| IPv4 unicast / multicast routes | 4096 / 2048 |
| IPv6 unicast / multicast routes | 2048 / 1024 |
| Number of VLANs | 4093 |
| ARP entries | 1500 |
| Ports | 24-port 10/100/1000BaseT PoE+ Ethernet Switch with 4 SFP/SFP+ uplink ports, GbE SFP optic/connector type: RJ-45, or LC SFP fiber supporting 1000BASE-T SFP, SX (multimode), LX (singlemode), or LH (single-mode) |
| Warranty | 1 Years |
