| Spesifikasi | |
|---|---|
| Print Method |
Impact dot matrix |
| Control Panel |
6 switches and 10 LEDs |
| Print Direction |
Bi-direction |
| Control Code |
ESC/P2, IBM PPDS |
| Number of Pins |
24 |
| Ultra High Speed Draft |
10 cpi: 550cps |
| High Speed Draft |
10 / 12 cpi: 487 / 584 cps |
| Draft |
10 / 12 cpi: 366 / 439 cps |
| NLQ |
10 / 12 cpi: 121 / 145 cps |
| Printhead Life |
400 million strokes / wire |
| Mean Print Volume Between Failure (MVBF) |
50 million lines (except print head) |
| Mean Time Between Failure (MTBF) |
25,000 Power On Hours (POH) (25% Duty) |
| Character Sets |
1 Italic and 12 graphical character tables: Italic table, PC437 (US, StandardEurope), PC850 (Multilingual), PC860 (Portuguese), PC861 (Icelandic), PC865 (Nordic), PC863 (Canadian-French), Abicomp, BRASCII, Roman 8, ISO Latin 1, PC858, ISO 8859-15 |
| Bitmap Fonts |
10, 12, 15 cpi |
| Scalable Fonts |
Epson Roman / Sans Serif / Roman T / Sans Serif H: 10.5pt., 8pt - 32pt. (every 2pt.) |
| Barcode |
EAN-13, EAN-8, Interleaved 2 of 5, UPC-A , UPC-E, Code 39, Code 128, POSTNET |
| Manual Insertion |
Front or Rear in-Top out |
| Push Tractor |
Front or rear in, top out |
| Pull Tractor |
Front, rear or bottom in, top out |
| Cut Sheet (Single Sheet) |
Entry: FrontLength: 100 - 364 mm (3.9 - 14.3”)Width: 100 - 257 mm (3.9 - 10.1”)Thickness: 0.065 - 0.14 mm (0.0025 - 0.0055”)Entry: RearLength: 100 - 364 mm (3.9 - 14.3”)Width:100 - 257 mm (3.9 - 10.1”)Thickness: 0.065 - 0.14 mm (0.0025 - 0.0055”) |
| Cut Sheet (Multi-part Forms) |
Entry: FrontLength: 100 - 364 mm (3.9 - 14.3”)Width: 100 - 257 mm (3.9 - 10.1”)Thickness: 0.12 - 0.46 mm (0.0047 - 0.018”)Copies: 1 Original + 5 copies |
| Continuous Paper (Single Sheet / Multi-part) |
Entry: Front, Rear, BottomLength: 101.6 - 558.8 mm (4.0 - 22.0”)Width: 101.6 - 254 mm (4.0 - 10.0”)Thickness: 0.065 - 0.49 mm (0.0025 - 0.019”)Copies: Original + 6 copies |
| Envelope (No.6) |
Entry: RearLength: 92mm (3.6”)Width: 165mm (6.5”)Thickness: 0.16 - 0.52 mm (0.0063 - 0.0205”) |
| Envelope (No.10) |
Entry: RearLength: 105mm (4.1”)Width: 241mm (9.5”)Thickness: 0.16 - 0.52 mm (0.0063 - 0.0205”) |
| Label (Base Sheet) |
Entry: BottomLength: 101.6 - 558.8 mm (4.0 - 22.0”)Width: 100 - 148 mm (3.9 - 5.8”)Thickness: 0.16 - 0.19 mm (0.0063 - 0.0075”) |
| Card |
Entry: Front, RearLength: 100 - 148 mm (3.9 - 5.8”)Width: 100 - 148 mm (3.9 - 5.8”)Thickness: 0.22mm (0.0087”) |
| Roll Paper |
Entry: RearDiameter: 127mm (5”)Width: 216mm (8.5”)Thickness: 0.07 - 0.09 mm (0.0028 - 0.035”) |
| Line Spacing |
4.23mm (1/6”) or programmable in increments of 0.0706mm (1/360”) |
| Temperature |
5 - 35 C*2 |
| Humidty |
10 - 80% RH*2 |
| Acoustic Noise |
55dB |
| Input Data Buffer |
128KB |
| Interface |
USB 2.0, Bi-directional parallel USB 2.0, Bi-directional parallel(IEEE-1284 nibble mode supported) |
| Pitch |
10cpi: 80 columns |
| Standard |
Fabric Ribbon Cartridge (Black) |
| Ribbon Life |
Approx. 5 million Characters |
| Garansi |
1 Years Local Dsitributor |
