| Panel Size |
86inch |
| Type/Tech |
TFT LCD Module with DLED Backlight |
| Display Area (mm) |
1895.04(H) x 1065.96(V) (85.6inch Diagonal) |
| Aspec Ratio |
16;9 |
| Native Resolution |
UHD 3840x2160(Pixels) |
| Colors |
1.07B Colors (10bit) |
| Brightness |
350 nits (typ.) 300 nits (min.) |
| Contras Ratio |
1200;1 Typ. |
| Response Time |
9ms |
| Viewing Angles |
H = 178, V=178 typ. |
| Backlight Life |
30,000 Hours (Min) |
| Surface Treatment |
Anti-Glare |
| Bezel |
Slim |
| Orientation |
Landscape |
| Touch Type/Tech |
IR Recognition |
| Touch Resolution |
32767 x 32767 |
| Touch Point |
20 Points Touch, 10 Points Writing |
| Input Connection |
HDMI 2.0 x3 (3840x2160 @60Hz) | RGB/VGA x1 | Audio x1 (PC Audio In) | CVBS x1 | RS232 1x | OPS x1 PC Slot (Proprietary) |
| Output Connection |
HDMI x1 | Audio x1 (Earphone out) | SPDIF 1 (Optical) | RS232 x1 |
| LAN |
RJ45 x1 |
| USB Type A |
USB 2.0 x4 (Including 2 USB Port in from t) & USB 3.0 x2 (Including 1 USB Prot in from t) |
| USB Type B |
x2 for touch |
| Compability RGB PC/HDMI PC |
Refer to timing table |
| Compability CVBS |
480i |
| Compability HDMI |
3840x2160 |
| Embedded OS |
Android 7 |
| USB Support File Format |
Picture - BMP, JPEG, PNG | Video - Codec; MPEG1, MPEG2, MPEG2-PG, MPEG4, MKV | Audio - Codec; AAC, HEAAC, MPEG1, MPEG2 | Container AAC, M4A, MP3 |
| Basic Annotation Software |
myViewBoard |
| Pro Annotation Software |
myViewBoard for windows (Embedded in Windows Slot-in PC) |
| Wireless Presentation with Touch Feedback; Viewboard Cast |
Yes |
| Zoom |
Yes |
| ViewSonic Launcher |
Embedded |
| Special Feature |
All-in-One USB port (Combine Windows/Android USB port; no need to distinguish them anymore) | Front InchSmartPort USBInch to all channels |
| Simple LAN Sharing between IFP and slot-in device |
Yes |
| Power Voltage |
100-240VAC +/- 10% Wide Range |
| Power Consumption |
81W (Typ.) < 0.5 W (InchOffInch) |
| Ergonimics |
Wall Mount (VESA) 400 x 200 |
| Package Contents |
Power Cable (3 Meters) x4 | Remote Control | USB Cable (5 Meters) | AV Cable | Touching Pen x2 | Quick Start Guide | RS232 Adapter | Clamp x5 | Plate | Screw x8 | HDMI Cable |
| VPC15-WP Slot-In PC |
Intel Core i5 | DDR4 8GB | SSD 128GB | 802.11a/b/g/n/ac | Windows 10 Pro |
| VB-CAM-001 Slot-In PC |
1080p FHD Resolution | Ultra Wide Angle | Dual Microphone |
