| Image Sensor |
1 / 3Inch Progressive Scan CMOS |
| Signal System |
PAL/NTSC |
| Effective Pixels |
1920(H) x 1080(V) |
| Min.Illumination |
0.01 Lux @ (F1.2,AGC ON),0 Lux with IR 0.014 Lux @ (F1.4,AGC ON),0 Lux with IR |
| Shutter speed |
1/25 s to 1/50,000 s |
| Day/Night |
ICR |
| Wide Dynamic Range |
120 dB |
| Synchronization |
Internal synchronization |
| Video Frame Rate |
1080p@25fps/1080p@30fps |
| HD Video Output |
1 Analog HD output |
| CVBS Output |
1Vp-p Composite Output(75Ω / BNC) |
| S/N Ratio |
More than 52dB |
| Scene |
Indoor, Outdoor, Indoor1, LOW-LIGHT |
| Camera ID |
On/off (15 characters, position programmable) |
| AGC |
Support |
| D / N Mode |
Color/BW/EXT |
| White Balance |
ATW, AWC-SET, Indoor, Outdoor, Manual |
| Privasi masking |
On/Off, maximum 8 zones |
| Motion Detection |
On/Off, maximum 4 zones |
| BLC |
Support |
| Anti-flicker |
On / off |
| Power Supply |
12 VDC ; -A: 12 VDC, 24 VAC |
| Power Consumption |
2V DC: Max. 7W ; 24V AC: Max. 10W |
| Weather-proof |
IP66 |
| IR Range |
Up to 50m |
| Warranty |
2 Years |
