| Type |
A3 Desktop Type Sheet Fed Scanner |
| Scanning sensor unit |
CIS |
| Optical resolution |
600dpi |
| Light source |
RGB LED |
| Scanning side |
Simplex, Duplex, Skip blank pages |
| Interface |
USB 3.1/ Wired LAN |
| Dimensions (W x D x H) |
Tray Closed : 480 x 569 x 315 mm Tray Open : 480 x 723 x 390 mm |
| Weight |
Appox. 25.0kg |
| Power requirements |
AC 220-240V (50/60Hz) |
| Power Consumption |
Scanning: 66.5 W Sleep mode: 3.5 W or less |
| Operating Environment |
10 - 35�C (50 - 95�F), Humidity: 20 - 80% RH |
| Noise |
54 dB |
| Environmental compliance |
EPEAT Gold certified |
| Black and White |
120ppm/240ipm (A4, Landscape, 200dpi/300dpi) |
| Colour |
120ppm/240ipm (A4, Landscape, 200dpi/300dpi) |
| Output resolution |
150 x 150dpi, 200 x 200dpi, 240 x 240dpi, 300 x 300dpi, 400 x 400dpi, 600 x 600dpi |
| Output mode |
Detect Automatically, Black and White, Error Diffusion, Active Threshold, Advanced Text Enhancement, Advanced Text Enhancement II, 256-level Grayscale, 24-bit Colour |
| Suggested Daily Duty Cycle |
50,000 scans/day |
| Width |
50.8 - 305 mm |
| Length |
70 - 432 mm |
| Thickness |
Continuous Feeding: 20 - 209g/m2, 0.04 - 0.25 mm Non-Separation Mode: 20 - 255g/m2, 0.04 - 0.03 mm |
| Long document mode |
5,588mm max |
| Paper separation |
Retard Roller and Pre-separation method |
| Feeder capacity |
500 sheets |
| Others |
Barcode Recognition, 2D Code, Patch Code, Job Function, Ultrasonic Double-Feed Detection, Staple Detection, Dropout and Color Enhancement, Auto Page Size Detection, 3-D Color Correction, Image Rotation, Skip Blank Page, Edge Emphasis, Moir� Removal, Prevent Bleed Through / Remove Background, Contrast Adjustment, Shading Correction, Brightness Adjustment, Deskew, Border Removal, Scanning Side Selection, Scan Area Settings, Addon Settings, Text Orientation Recognition, Punch Hole Removal, Folio Scan, Unnecessary dots removal, Notch removal, Background Smoothing, Character Emphasis, Rapid Recovery System, MultiStreamTM |
| Windows |
ISIS Driver, TWAIN Driver (32/64bit), WIA Driver, Kofax VRS Driver CaptureOnTouch Pro Driver Setting Tool |
| Warranty |
3 Tahun |
