| Type |
Desktop Type Sheet Fed Scanner |
| Scanning sensor unit |
CMOS CIS 3 Line Sensor |
| Optical resolution |
600dpi |
| Light source |
RGB LED |
| Scanning side |
Front / Back / Duplex |
| Interface |
High speed USB 2.0 & SCSI-3 |
| Dimensions (WxDxH) |
Tray Closed: 398 × 312 × 191 mmTray Opened: 398 × 668 × 194 mm at U-turn path |
| Weight |
Approx. 10.5 kg |
| Power requirements |
AC220 - 240V (50/60Hz) |
| Power consumption |
Scanning: 46.5W, Sleep Mode:3.7W, Power Turned Off: 0.04W |
| Operating environment |
10 - 32.5°C (50 - 90.5°F), Humidity 20 - 80% RH |
| Environmental compliance |
RoHS and ENERGY STAR |
| Black and White |
80ppm / 160ipm - Landscape speed |
| Colour |
80ppm / 160ipm - Landscape speed |
| Output resolution |
100 x 100dpi, 150 x 150dpi, 200 x 200dpi, 240 x 240dpi, 300 x 300dpi, 400 x 400dpi, 600 x 600dpi |
| Colour mode |
B&W, Error Diffusion, High speed Text Enhancement, Advanced Text Enhancement, Advanced Text Enhancement II, 8-bit (256 level) Greyscale, 24-bit colour |
| Suggested Daily Duty Cycle |
Approx: 10,000 scans/day |
| Width |
53 - 300mm |
| Length |
70 - 432mm |
| Thickness |
Separation On: (U-turn/Straight Through) 52 - 128g/m² (0.06 - 0.15mm）Separation Off: (U-turn) 42 - 157g/m² (0.05 - 0.20mm）(Straight Through) 42 - 546g/m² (0.05 - 0.66mm） |
| Long document mode |
3000mm Max (Selectable in MS Windows control panel) |
| Paper separation |
Retard Roller |
| Feeder capacity |
100 Sheets (80g/m²) |
| Others |
Deskew, Auto Page Size Detection, Skip Blank Page, Text Orientation Recognition, Preset Gamma Curve, Colour Dropout (RGB/Custom Colour) / Enhancement (RGB/Custom Colour), Erase Dot, Border Removal, Punch Hole Removal, Batch Separation, Edge Enhancement, Prescan, Scan Area Setting, MultiStreamâ„¢, Patch Code, Separate Front/Back settings, Ultrasonic Double Feed Detection, User Registration |
| Windows |
ISIS/TWAIN Drivers (Windows 2000/XP Pro/XP Home/Vista/7/8/10), CapturePerfect, Kofax VRS |
| Warranty |
3 Tahun |
