| Type |
Desktop Type Sheet Fed Scanner |
| Scanning sensor unit |
CMOS CIS 3 Line Sensor |
| Optical resolution |
600dpi |
| Light source |
RGB LED |
| Scanning side |
Front / Back / Duplex |
| Interface |
Dual Interface (High speed USB 2.0 & SCSI-3) |
| Dimensions (WxDxH) |
Tray Closed: 318 × 278 × 185.5 mmTray Opened: 318 × 545 ×187 mm at U-Turn path |
| Weight |
Approx. 6.5 kg |
| Power requirements |
AC220 - 240V (50/60Hz) |
| Power consumption |
Scanning: 30W, Sleep mode:2.2W |
| Operating environment |
10 - 32.5°C (50 - 90.5°F), Humidity: 20 - 80% RH |
| Environmental compliance |
RoHS and ENERGY STAR |
| Black and White |
60ppm / 120ipm |
| Colour |
60ppm / 120ipm |
| Output resolution |
100 x 100dpi, 150 x 150dpi, 200 x 200dpi, 240 x 240dpi, 300 x 300dpi, 400 x 400dpi, 600 x 600dpi |
| Colour mode |
Black and White, Error Diffusion, Advanced Text Enhancement, Advanced Text Enhancement II, 8-bit Greyscale (256-Level), 24-bit Colour, High speed Text Enhancement |
| Suggested Daily Duty Cycle |
Approx: 7,500 scans/day |
| Width |
53-219mm |
| Length |
70-356mm |
| Thickness |
Automatic Feeding/U-Turn: 52 - 128g/m² (0.06- 0.15mm)Automatic Feeding/Straight Path: 52 - 128g/m² (0.06- 0.20mm)Bypass Mode/U-Turn: 52 - 157g/m² (0.06- 0.20mm)Bypass Mode/Straight Path: 52 - 546g/m² (0.06- 0.66mm) |
| Long document mode |
3000mm max. (Adjustable in MS Windows control panel) |
| Card scanning |
Width: 53.0mm, Length: 85.5mm, Thickness: 0.76mm (Straight Path & Bypass Mode only) |
| Paper separation |
Retard Roller |
| Feeder capacity |
100 Sheets (80g/m²) |
| Others |
Auto Page Size Detection, Deskew, Skip Blank Page, Text Oriantation Recognition, Auto Colour Detection, Colour Dropout (RGB/Custom), Enhancement (RGB/Custom), Moire Reduction, Prevent Bleed through/Remove Background, Border Removal, Batch Separation, Patch Code Separation (software), Punch Hole Removal, Scan Area Setting, MultiStreamâ„¢, Rapid Recovery System, Ultrasonic Double Feed Detection, Job/User Registration |
| Windows |
ISIS /TWAIN Driver (Windows 2000 / XP / VISTA / 7 / 8 / 10)CapturePerfectKofax VRS |
| Warranty |
3 Tahun |
