| Type |
Desktop Type Sheet Fed Scanner |
| Scanning sensor unit |
CMOS CIS 1 Line Sensor |
| Optical resolution |
600dpi |
| Light source |
RGB LED |
| Scanning side |
Front / Back / Duplex |
| Interface |
USB 2.0 (USB 3.0 compatible) |
| Dimensions (WxDxH) |
Tray Closed : 280 x 172 x 178 mmTray Opened : 280 x 606 x 366.4 mm |
| Weight |
Approx. 3.2kg |
| Power requirements |
AC100 - 240V (50/60Hz) |
| Power consumption |
Scanning 27W or less, Sleep Mode 1.8W or less, Power Turned Off less than 0.5W |
| Operating environment |
10 - 32.5 �C (50 - 90.5 �F), Humidity: 20 - 80% RH |
| Environmental compliance |
RoHS and ENERGY STAR |
| Black and White |
60ppm / 120ipm |
| Colour |
60ppm / 120ipm |
| Output resolution |
150 x 150dpi, 200 x 200dpi, 240 x 240dpi, 300 x 300dpi, 400 x 400dpi, 600 x 600dpi |
| Colour mode |
Black & White/Error Diffusion/ Advanced Text Enhancement (Windows only),Advanced Text Enhancement II, 8-bit Greyscale (256-Level), 24-bit Colour |
| Suggested Daily Duty Cycle |
Approx 7,000 scans/day |
| Width |
50.8 - 216mm |
| Length |
54 - 356mm |
| Thickness |
27 - 209g/m� (0.04 - 0.25mm) |
| Long document mode |
3000mm Max (selectable in MS Windows control panel) |
| Card scanning |
Width: 53.9mm Length: 85.5mm Thickness: 0.76mm (Embossed Card is supported) |
| Paper separation |
Retard Roller Method |
| Feeder capacity |
75 Sheets (A4, 80g/m�) |
| Others |
Automatic Page Size Detection, Deskew, 3- Dimentional Colour Correction, Colour Dropout (RGB), Colour Enhancement (RGB), Auto Colour Detection, Shading Correction, MultiStream, Preset Gamma Curve, Skip Blank Page, Folio Mode, Scan Area Setting, Patch Code, Batch Separation with white blank sheet (Windows only), Edge Enhancement, Moire Reduction, Prevent Bleed Through/Remove Background, Contrast Arrangement, Colour Drift, Adding Black Margin Mode, Colour Elimination, Background Smoothing, Shadow Cropping, Auto Resolution Setting, Stretch Adjustment of Sub-Scanning Direction, Double Feed Release, Thin Paper Mode, Double Feed Detection (Ultrasonic Sensor/ By Length), Separation Retry |
| Windows |
ISIS / TWAIN Driver (Windows XP / Vista / 7 / 8 /8.1 / 10) CaptureOnTouch Pro CapturePerfect eCopy PDF Pro Office Kofax VRS |
| Mac |
TWAIN DriverCaptureOnTouch |
| Warranty |
3 Tahun |
