| Type |
Desktop Type Sheet Fed Scanner |
| Scanning sensor unit |
CMOS CIS 1 Line Sensor |
| Optical resolution |
600 dpi |
| Light source |
RGB LED |
| Scanning side |
Front / Back / Duplex |
| Interface |
High speed USB 2.0 |
| Dimensions (WxDxH) |
Trays Closed: 291 x 253 x 231 mmTrays Opened: 291 x 603 x 363 mm |
| Weight |
Approx. 2.8kg |
| Power requirements |
AC 100-240V (50/60Hz) |
| Power consumption |
Scanning: 19W or lessSleep Mode: 1.4W or lessPower Turned Off: 0.1W or less |
| Operating environment |
10 - 32.5 °CHumidity: 20 - 80% RH |
| Environmental compliance |
RoHS and ENERGY STAR |
| Black and White |
45ppm / 90ipm |
| Colour |
30ppm / 60ipm |
| Output resolution |
150 x 150dpi, 200 x 200dpi, 240 x 240dpi, 300 x 300dpi, 400 x 400dpi, 600 x 600dpi |
| Output mode |
Black & White/Error Diffusion/ Advanced Text Enhancement, Advanced Text Enhancement II, 8-bit Greyscale (256-Level), 24-bit Colour |
| Suggested Daily Duty Cycle |
Approx. 4000 scans |
| Width |
50.8 - 216mm |
| Length |
54 - 356mm |
| Thickness |
27 - 209g/m² (0.06 - 0.25mm) |
| Long document mode |
3000mm Max |
| Business card scanning |
Size: 50.8 x 85mm or largerThickness: Less than 0.45 mm |
| Plastic card scanning |
Size: 53.9 x 85.5mmThickness: 0.76mm (Embossed Card up to 1.4mm thick is supported) |
| Passport scanning |
Up to 4mm thick (via carrier sheet) |
| Paper separation |
Retard Roller Method |
| Feeder capacity |
60-sheets (80g/m²) |
| Windows |
ISIS / TWAIN Driver (Windows VISTA SP2 / 7 SP1 / 8 / 8.1 / Server 2008 R2 SP1 / Server 2012 R2) CaptureOnTouch ProCapturePerfecteCopy PDF Pro OfficeKofax VRS |
| Mac |
TWAIN DriverCaptureOnTouchCapturePerfecteCopy PDF Pro OfficeKofax VRS |
| Warranty |
3 Tahun |
