| Type |
USB Powered Sheetfed Scanner |
| Scanning sensor unit |
CMOS CIS 1 Line Sensor |
| Optical Resolution |
600 dpi |
| Light source |
RGB LED |
| Scanning side |
Front / Back / Duplex |
| Interface |
Hi speed USB 2.0 & USB 3.0 |
| Dimensions (WxDxH) |
Tray Closed : 285 x 95 x 40 mmTray Opened : 285 x 257 x 174 mm |
| Weight |
Approx. 1.0kg |
| Power Requirements |
USB 2.0 bus power: 0.5A (1.0A in combination with power supply USB cable) USB 3.0 bus power: 0.9AOptional AC Adaptor DC6V. 0.8A |
| Power Consumption |
USB cable only: 2.5W (USB 2.0), 4.5W (USB 3.0)USB cable and power supply USB cable: 5.0W (USB 2.0), 7.0W (USB 3.0)Sleep mode: 1.5W, Power OFF: 0.1W |
| Operating environment |
10 - 32.5ºC (50 - 90.5ºF), Humidity: 25 - 80% RH |
| Environmental compliance |
RoHS and ENERGY STAR |
| Black and White |
With USB 3.0: 15ppm / 30ipm, with USB 2.0: 12ppm / 14ipm |
| Colour |
With USB 3.0: 10ppm / 20ipm, with USB 2.0: 10ppm / 10ipm |
| Output resolution |
150 x 150dpi, 200 x 200dpi, 300 x 300dpi, 400 x 400dpi, 600 x 600dpi |
| Colour mode |
Black & White, Error Diffusion, Advanced Text Enhancement II, 8-Bit Greyscale: (256-Level), 24-Bit Colour, Auto Colour Detection |
| Suggested Daily Duty Cycle |
Approx 500 scans / day |
| Width |
50.8 - 216mm |
| Length |
70 - 356mm |
| Thickness |
52 - 128g/m² (0.06 - 0.15mm) |
| Long document mode |
Up to 1,000mm |
| Card scanning |
54 x 86 x 1.4mm (Embossed card scanning is supported) |
| Paper separation |
Separation Pad Method |
| Feeder capacity |
20 sheets (64g/m²) |
| Others |
Automatic Page Size Detection, Deskew, 3- Dimensional Colour Correction, Colour Dropout (RGB), Auto Colour Detection, Shading Correction, Text Enhancement, MultiStream, Preset Gamma Curve, Scan Panel, Prescan, Image Rotation, Skip Blank Page, Select Scanning Document Side, Scan Area Setting, Text Orientation, Continuous Scanning, Edge Enhancement, Moire Reduction, Prevent Bleed Through/Remove Background, Contrast Arrangement, Colour Drift, Background Smoothing, Shadow Cropping (on/off switchable), Trimming, Corrections suitable for photographs, Auto Resolution Setting |
| Windows |
ISIS /TWAIN Driver (Windows XP Pro / XP Home / VISTA / 7 / 8 / 10)CaptureOnTouchCaptureOnTouch LiteCardiris |
| Mac |
TWAIN Driver CaptureOnTouchCaptureOnTouch Lite |
| Warranty |
3 Tahun |
