| Type |
USB Powered Sheetfed Scanner |
| Scanning Sensor |
CMOS CIS 2 Line Sensor |
| Optical Resolution |
600 dpi |
| Light Source |
RGB LED |
| Scanning Side |
Front/Back/Duplex |
| Interface |
Hi Speed USB 2.0 |
| Dimension (WxDxH) |
Tray Closed : 312.5 x 56.5 x 40 mmTray Opened : 312.5 x 89.5 x 40 mm |
| Weight |
Approx 600g |
| Power Reuirments |
Supply from USB (500mA) |
| Power Consumption |
Scanning : 2.5WSleep Mode : 1.5WPower Turned Off : 0.5W |
| Environmetal compaliance |
RoHS and Energy Star |
| Black and White |
8 ppm / 16 ipm |
| Color |
8 ppm / 16 ipm |
| Output resolution |
150 x 150dpi, 200 x 200dpi, 300 x 300dpi, 400 x 400dpi, 600 x 600dpi |
| Colour mode |
Black & White, Advanced Text Enhancement II, 8-Bit Greyscale: (256-Level), 24-Bit Colour |
| Suggested Daily Duty Cycle |
Approx 100 scans / day |
| Width |
50.8 - 216mm |
| Length |
70 - 356mm |
| Thickness |
52 - 209g/m� (0.06 - 0.22mm) |
| Card scanning |
54 x 86 x 1.4mm (Embossed card scanning is supported) |
| Paper separation |
Separation Pad Method |
| Feeder capacity |
10 sheets (64g/m�) |
| Others |
Automatic Page Size Detection, Deskew, 3- Dimentional Colour Correction, Auto Colour Detection, Shading Correction, Text Enhancement, Preset Gamma Curve, Scan Panel, Prescan, Image Rotation, Skip Blank Page, Select Scanning Document Side, Scan Area Setting, Text Orientation Recognition, Continuous Scanning, Edge Enhancement, Moire Reduction, Prevent Bleed Through/Remove Background, Contrast Arrangement, Background Smoothing, Shadow Cropping (ON/OFF Switchable), Trimming, Apply Corrections Suitable For Photographs, Double Feed Detection (By Length) |
| Windows |
ISIS /TWAIN Driver (Windows XP Pro / XP Home / VISTA / 7 / 8 / 10)CaptureOnTouchCaptureOnTouch LiteCardiris |
| Mac |
TWAIN DriverCaptureOnTouchCaptureOnTouch Lite |
| Warranty |
3 Tahun |
