| Spesifikasi | |
|---|---|
| Features | STP Bridge Protocol Data Unit (BPDU) Guard : This security mechanism protects the network from invalid configurations. A port enabled for BPDU Guard is shut down if a BPDU message is received on that port; Secure Shell (SSH) Protocol : SSH is a secure replacement for Telnet traffic. SCP also uses SSH. SSH v1 and v2 are supported; Flexible network management capabilities : Remote management. Using SNMP, you can set up and manage all switches and other Cisco devices in your network remotely. Command-Line Interface (CLI). The switches can be managed using a CLI. This capability can enable scripted or automated deployment for network professionals; Secure Sockets Layer (SSL) : SSL support: Encrypts all HTTPS traffic, allowing highly secure access to the browser-based management GUI in the switch |
| Part Number | SG220-26-K9-EU |
| Ethernet | 24 x Gigabit Ethernet RJ-45 ; 26 Gigabit Ethernet |
| WiFi | No |
| Weight | 2.81 kg |
| Dimension | 440 x 44 x 201 mm |
| I/O Ports | Inch24xGigabit Ethernet RJ-45 + uplink 2xGigabit Ethernet combo |
| Spesifikasi | memory : 128 MB ; IEEE 802.3 10BASE-T Ethernet, IEEE 802.3u 100BASE-TX Fast Ethernet, IEEE 802.3ab 1000BASE-T Gigabit Ethernet, IEEE 802.3ad LACP, IEEE 802.3z Gigabit Ethernet, IEEE 802.3x Flow Control, IEEE 802.1D (STP, GARP, and GVRP),IEEE 802.1Q/p VLAN, IEEE 802.1w RSTP, IEEE 802.1s Multiple STP, IEEE 802.1X Port Access Authentication, IEEE 802.3af, IEEE 802.3at, RFC 768, RFC 783, RFC 791, RFC 792, RFC 793, RFC 813, RFC 879, RFC 896, RFC 826, RFC 854, RFC 855, RFC 856, RFC 858, RFC 894, RFC 919, RFC 922, RFC 920, RFC 950, RFC 1042, RFC 1071, RFC 1123, RFC 1141, RFC 1155, RFC 1157, RFC 1350, RFC 1533, RFC 1541, RFC 1624, RFC 1700, RFC 1867, RFC 2030, RFC 2616, RFC 2131, RFC 2132, RFC 3164, RFC 3411, RFC 3412, RFC 3413, RFC 3414, RFC 3415, RFC 2576, RFC 4330, RFC 1213, RFC 1215, RFC 1286, RFC 1442, RFC 1451, RFC 1493, RFC 1573, RFC 1643, RFC 1757, RFC 1907, RFC 2011, RFC 2012, RFC 2013, RFC 2233, RFC 2618, RFC 2665, RFC 2666, RFC 2674, RFC 2737, RFC 2819, RFC 2863, RFC 1157, RFC 1493, RFC 1215, RFC 3416 |
| Power | 100-240 V, 50-60 Hz |
| Warranty | Smartnet 5 year |
| Kelengkapan Paket | Cisco 220 Series Ethernet switch; Power cord; Mounting kit included in all SKUs; Console cable; Quick start guideInch |
| Others | Mean Time Between Failure (MTBF) : 342,867 (hours); Packet Buffer : 4.1 Mb; Support for up to 256 VLANs simultaneously Port-based and 802.1Q tag-based VLANs Management VLAN Guest VLAN ; Switching Capacity : 52 Gbps ; Flash : 32 MB; ACL : Drop or rate limit based on source and destination MAC, VLAN ID or IP address, protocol, port, differentiated services code point (DSCP)/IP precedence, TCP/UDP source and destination ports, 802.1p priority, Ethernet type, Internet Control Message Protocol (ICMP) packets, IGMP packets, TCP flag Support up to 512 rules ; Packet Forwarding Rate : 38.69 mpps ; MAC Address Table : Up to 8192 MAC addresses; Jumbo Frame : Frame sizes up to 9216 supported ; Packet Buffer Memory : 4.1 Mb ; IPv6 : IPv6 host mode IPv6 over Ethernet IPv6/IPv4 Dual Stack IPv6 neighbor and router discovery (ND) IPv6 stateless address auto-configuration Path maximum transmission unit (MTU) discovery Duplicate address detection (DAD) ICMP version 6 ; IPv6 Applications : Web/SSL, Telnet server/SSH, DHCP Client, DHCP Autoconfig, CDP, LLDP |
| Serviceability | Priority levels : 8 hardware queues per port ; Scheduling : Strict priority and weighted round-robin (WRR) queue assignment based on DSCP and class of service (802.1p/CoS); Class of service : Port-based; 802.1p VLAN priority-based; IPv4/v6 IP precedence, type of service (ToS), and DSCPbased; Differentiated Services (DiffServ); classification and re-marking ACLs, trusted QoS; Rate limiting : Ingress policer; egress shaping and rate control; per VLAN, per port, and flow-based; IPv6 QoS : Prioritize IPv6 packets in hardware; IPv4 and IPv6 dual stack : Coexistence of both protocol stacks to ease migration; Auto Voice VLAN : Voice traffic is automatically assigned to a voice-specific VLAN and treated with appropriate levels of QoS; QinQ VLAN : VLANs transparently cross a service provider network while isolating traffic among customers; GVRP and GARP : Protocols for automatically propagating and configuring VLANs in a bridged domain |
| Fitur | Congestion Avoidance : A TCP congestion avoidance algorithm is required to reduce and prevent global TCP loss synchronization; IGMP Versions 1, 2, and 3 Snooping : IGMP limits bandwidth-intensive multicast traffic to only the requesters; supports 256 multicast groups; IGMP Querier : IGMP querier is used to support a Layer 2 multicast domain of snooping switches in the absence of a multicast router; IPv6 ACL : Drop or rate limit IPv6 packets in hardware; CPU Memory : 128 MB |
| Teknologi | Head-of-line (HOL) blocking : HOL blocking prevention; Spanning Tree Protocol (STP) : Standard 802.1d Spanning Tree support, enabled by default Fast convergence using 802.1w (Rapid Spanning Tree [RSTP]) Multiple Spanning Tree instances using 802.1s (MSTP) 16 instances are supported; Port grouping : Support for IEEE 802.3ad Link Aggregation Control Protocol (LACP) ? Up to 8 groups ? Up to 8 ports per group with 16 candidate ports for each (dynamic) 802.3ad link aggregation Load balance based on source and destination MAC address, or source and destination MAC/IP; IEEE 802.1X (Authenticator role) : 802.1X: RADIUS authentication; guest VLAN; multiple host mode; Port security : Creates the ability to lock source MAC addresses to ports; limits the number of learned MAC addresses ; Storm control : Broadcast, multicast, and unknown unicast ; DoS prevention : DOS attack prevention |
