| Spesifikasi | |
|---|---|
| Network Standard | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.3ad, IEEE 802.3az, IEEE 802.1d, IEEE 802.1Q/p, IEEE 802.1X |
| Memory | 128MB� |
| Forwarding Rate: | 11.90 Mpps� |
| LEDs | System (blue), Link/Act (green)� |
| Switching Capacity: | 16 Gbps� |
| Jumbo Frame (FE, GE): | 9K� |
| MAC Address Table Size: | 8K |
| Dimensions (LxWxH): | 210 x 104 x 25 mm (8.3 x 4.1 x 1.0 in.)� |
| Power Consumption: | System Power Consumption without PoE+: 110V:9.95W, 220V:10.17W |
| Power Dedicated to PoE | 72W |
| Port Mirroring | Traffic on multiple ports (up to four ports) can be mirrored to another port for analysis with a network analyzer |
| Security | 802.1x Radius Authentication, DHCP Snooping, IP-MAC Binding, Management Access Control, Port Security Supports Limited Dynamic Lock and Locked MAC Address |
| Features | IEEE 802.1d/w Spanning Tree Supports, Link Aggregation IEEE 802.3ad LACP, VLAN, Auto Voice VLAN, IGMP v1/v2/v3 Snooping, Head-of-Line Blocking Prevention Ready, Storm Control (Broadcast, Flooding, Multicast), Embeded RMON Supports |
| Interface | 8x Copper PE/GE RJ45 Ports, PoE+ Ports (ports 1-8) |
| QoS | Class of Service (Port-based, 802.1p Priority-based, IPv4/v6 IP DSCP Based), Priority Levels (4 Hardware Queues), Scheduling (Priority Queuing and Weighted Roudn Robin) |
| Others | Management Interface (HTTP, HTTPS, Telnet, DHCP Client, System Log, PING, Dual Images, SNTP, Configuration Unload and Backup via HTTP/TFTP), SNMP (Version 1, Version 2c), Mac Address 8K |
| Weight | 0.562 kg |
| Warranty | Limited Lifetime |
