| Spesifikasi | |
|---|---|
| Baterai |
12 V / 9 AH, 2, Battery Type: Depending on the capacity of external batteries |
| Daya Keluar |
1000VA/800W |
| Form Factor |
Mini Tower |
| Lain-lain |
Charging Current (max.): 1A, Charging Voltage: 27.4VDC �1%, Battery Type: Depending on the capacity of external batteries, Charging Current (max.): 1A/2A/4A/6A (Adjustable), Linear Load: 3 Percent THD, Non-Linear Load: 6 Percent THD, LCD Panel: Load Level, Battery Level, AC mode, Bypass mode, and Fault Conditions, Battery Model: Sounding every 4 seconds, Low Battery: Sounding every seconds, Overload: Sounding twice every seconds, Fault: Continuously sounding, Humidity: 20~90 Percent RH 0~40C Non-Condensing, Noise Level: Less than 50dB 1 Meter, Smart RS232 / USB: Support Windows 2000/2003/XP/Vista/2008, Windows 7/8, Linux, Unix and MAC, Optional SNMP: Power management from SNMP manager and web browser, Typical Recharge Time : 4 hours recover to 90% capacity |
| Dimensi Produk |
Standard Model : 282 x 145 x 220 mm (D�W�H), Long-Run Model: 282 x 145 x 220 mm |
| Berat Produk |
Standard Model: 9.8 KG, Long-Run Model: 4.1 KG |
| Voltase Masuk |
Nominal Voltage : 100/110/115/120/127VAC or 200/208/220/230/240VAC, Input Voltage Range : 55-150VAC or 110-300VAC (Based on load at 50%); 85-140VAC or 160-280VAC (Based on load at 100%), Frequency Range : 40Hz ~ 70Hz, Power Factor : ≥ 0.99 @Nominal Voltage (100% load) |
| Voltase Keluar |
Output AC Voltage : 100/110/115/120/127VAC or 200/208/220/230/240VAC, Voltage Regulation : ±1%, Frequency Range (Synchronized Range) : 47 ~ 53Hz or 57 ~ 63Hz, Frequency Range (Battery Mode) : 50Hz ±0.25Hz or 60Hz ± 0.3Hz, Current Crest Ratio : 3 : 1, Harmonic Distortion : Linear Load ≤3% THD; Non-Linear Load ≤6% THD, Transfer Time : AC Mode to Battery Mode Zero; Inverter to Bypass 4ms (Typical), Waveform (Battery Mode) : Pure Sinewave |
| Antarmuka / Interface |
Smart RS232, USB |
| Garansi |
24 Bulan dari Distributor Resmi di Indonesia |
