Capacity : 2000 VA
Input
Voltage Range : 140 - 300V A +/- 5%
Frequency : 50Hz/60Hz (Auto-sensing)
Phase : Single + GND
Output
Voltage Range : 230VAC +12% -14%
Battery Mode : 230VAC +10% -10%
Frequency : 50Hz A +/- 1% (Battery Mode)
Waveform :
- Simulated Sine Wave (Battery Mode)
- Sine Wave (AC Mode)
Transfer Time :2ms typical
Battery Type :12V/9AH - 2pcs
Backup Time :Up to 40 mins depending on load
Recharge Time : 2 - 4 hours recover to 90% capacity
Protection / Monitoring :
Short Circuit Protection : Yes (Line Mode and Battery Mode)
Surge Protection : Yes
Alarm : Audible & Visual
UPS Protection : Load auto sensing and abnormal protection
Overload Protection : - Line mode : 110 - 120% 5 mins change to fault mode>120% shutdown immediately
- Battery mode : 100 - 110% alarm & shutdown in 10 secs >120% shutdown immediately
Intelligent Battery Management :
Prevent overcharging of battery
Protect battery and prolong battery life
Interface Interface : RJ11
USB Connector : AC fault, battery low, shutdown UPS
General
Software : Support Windows 2000/ 2003/ XP/ Vista/ 2008/ 7/8/10, Linux, and Mac
Noise Level : <40dB
Temperature : 0A°C - 40A°C
Humidity : 0 - 90%
Power Factor : Up to 0.7
Built in AVR : TRUE Full AVR (3 steps)
Physical Dimension (mm) D x W A— H
320 x 130 x 182 mm (product only)
390 x 192 x 275mm (with box)
Net Weight (kgs) :
8.2KG (product only)
9KG (with box)
2 Tahun board & 1 Tahun Battery
