| Panel Size |
3LCD 20mm (0.79Inch) |
| Resolution |
XGA (1024 x 768) |
| Light Output (Brightness) ANSI Lumens |
8000 (Normal), 6400 (Eco) |
| Contrast Ratio |
10,000:1 |
| Lamp Life (Hours) |
2000 (Normal), 4000 (Eco) |
| Lens |
Interchangeable, not included |
| Lens Zoom |
Powered Zoom x 1.7 |
| Lens Focus |
Powered Focus |
| Throw Distance |
1.1 – 37.6m (ML-713) |
| Distance to Width Ratio/ Throw Ratio (:1) |
1.5 (Wide), 2.5 (Tele) |
| Digital Input |
HDMI x 2, HDBaseT x 1, DisplayPort x 1 |
| Analogue Input |
15 pin Mini D-Sub x 1, RCA Jack x1 |
| Video Output |
15 pin Mini D-Sub x 1 |
| Audio Input |
3.5mm Stereo Mini Jack x 1, RCA Jack (L/R) x 1 |
| Audio Output |
RCA Jack (L/R) x1 |
| RS-232C Control |
1 x 9-pin D-Sub |
| Wireless LAN |
Yes (Optional) |
| Wired LAN |
Yes |
| USB Type A |
Used for PC-less presentation, wireless network or optional wireless pen tablet TB-1 |
| USB Type B |
Used for Remote control mouse or PC screen display |
| Power Supply |
AC 100V-120V / AC 220V-240V (50/60 Hz) |
| Operating Power Consumption |
560W |
| Compatibility Computer |
IBM Compatible VGA, SVGA, XGA, WXGA, WXGA+/SXGA/SXGA+/WSXGA+/UXGA/WUXGA, MAC16Inch |
| Compatibility Video |
525i(480i), 525p(480p), 625i(576i), 625p(576p)1125i(1080i@50/60), 750p(720p@50/60), 1125p(1080p@50/60) |
| Supplied Accessories |
Power Cable (1.8m) x1, Computer Cable (2m) x1, IR Remote Control Unit x1, Security Label x1, AA Batteries x2, Application CD (for network, etc.) x1, CD User Manual x1, Concise User Manual x1, Adapter Cover x1, Terminal Cover x1, HDMI Bracket x2, Binder x2 |
| Garansi |
Garansi Resmi 3 tahun - Lampu 2 thn / 1000jam |
