| Spesifikasi | |
|---|---|
| Image Sensor Type | Contact Image Sensor at 600 dpi Automatic Black and White Background Reference |
| Light Source | RGB LED |
| Optical Resolution | 100 – 600 DPI (1 DPI step) Optical: 600 DPI (Main and sub feeding directions) |
| Output Resolution | Color: 24-bit |
| Output Color Depth | Color: 24-bit |
| Image Processing Function | Auto Preview, Auto Rescan, Dynamic Threshold, White Level From, Paper, Image Emphasis, Automatic Separation, Invert, Border , Removal, Despeckle, Auto Rotation, Smoothing, Barcode Detection |
| Scanning Speed | Up to 100 PPM Simplex: LTR/A4 Landscape (200/300DPI), Up to 200 IPM Duplex: LTR/A4 Landscape (200/300DPI) |
| Adf Capacity | Up to 200 Sheets: 20lbs. (80 g/m2) |
| Document Size | ADF Manual Feeding: 1.9 x 2.75 in. to 11.9 in. x Unlimited, ADF Automatic Feeding: 1.9 x 2.75 in. to 11.9 x 17 in |
| Flatbed | Maximum Size: 11.7 x 17 in |
| Weight (Thickness) | 8.3 - 34 lbs.3, Smaller than A7 size: 34 lbs. only |
| Interface | USB 3.0 interface |
| Power Requirments | AC 100-127 V, 50/60 Hz, 1.5 A, AC 100-240 V, 50/60 Hz, 1.5-0.8 A, AC 220-240 V, 50/60 Hz, 0.8 A |
| Power Consumption | Maximum (scanning) 90 W: 1.5 A (100-127 V), 90 W: 0.8 A (220-240 V), Minimum (ready): 38 W (100-127 V / 220-240 V), Sleep: 1.4 W or less (100-127 V / 220-240 V), Power Off: 0.3 W or less (100-127 V / 220-240 V) |
| Dimensions Product Dimension (W X D X H) | 29.7 x 20.0 x 11.4 in. |
| Weight | 64 lbs. (66 lbs. includes accessories) |
| Inbox Contents | CD-ROM: Device driver, ISIS driver software, TWAIN driver software,User utility, Scan Button Setting Tool, Image Capture Plus, PowerCord, USB 3.0 Cable, Quick Installation Guide |
| Bundled Software | Panasonic Image Capture Plus, EMC Quick Scan Pro (Trial),Panasonic User Utility, TWAIN Driver, ISIS Driver, WIA Driver |
| Option | Roller exchange kit: KV-SS015, Roller cleaning paper: KV-SS03,Imprinter Unit (Pre): KV-SS0144, Ink cartridge: KV-SS021, Kofax®VRS Elite 5 (KV-S7097-V), Network Scanner Option: KV-SSM100, SiteCentral Management Software |
| Os Support | Windows® XP SP3 (32bit/64bit), Windows Vista® SP2 (32bit/64bit), Windows® 7 (32bit/64bit), Windows® 8 (32bit/64bit), Windows® 8.1 (32bit/64bit), Windows® 10 (32bit/64bit), Windows Server® 2003 SP2 (32bit/64bit), Windows Server® 2003 R2 SP2 (32bit/64bit), Windows Server® 2008 SP2 (32bit/64bit), Windows Server® 2008 R2 SP1 (64bit),Windows Server® 2012 (64bit) |
| Feed Detection Features | Ultrasonic Double-Feed Detection, Intelligent Double Feed Detection |
| Warranty | 3 Years Limited |
