| Spesifikasi | |
|---|---|
| Model No. |
KV-S5076H |
| Scanning Face |
Duplex |
| ADF Capacity 80g/m2 |
300 |
| Scanning Method |
Front side: CIS (600 dpi) Back side: CIS (600 dpi)Selectable black and white background reference |
| Scanning Speed | |
| Binary / Colour A4 size (Landscape) 200 / 300 dpi |
Simplex : Up to 100 ppm. Duplex : Up to 200 ipm |
| Binary / Colour A4 size (Portrait) 200 / 300 dpi |
Simplex : Up to 80 ppm, Duplex : Up to 160 ipm |
| Resolution |
100 – 600 dpi (1 dpi step), Optical: 600 dpi (Main and Sub feeding directions) |
| Detection |
Double feed detection, Staple document detection, Skew detection, Jam detection, Slip detection, Dog ear detection |
| Compression |
JPEG (colour, grayscale), MH, MMR (Software ICP) |
| Tonal Gradation |
Binary, Grayscale (8 bit), Colour, MultiStream : Binary & Grayscale, Binary & Colour |
| Binary Mode Halftone |
Dither, Error diffusion |
| Image Control |
Auto preview, Auto rescan, Image emphasis, Dynamic threshold, Automatic separation, Invert, White level from paper, Automatic Colour Detection, Autocrop, Deskew, dan Multifeed Detection |
| Other Functions |
Length control, Barcode detection (ISIS), Patch code detection, Control sheet, Long paper mode |
| Maximum Image Size |
307 x 2,540 mm (12.09 x 100 in.) |
| Documents Size |
Minimum : 48 x 70 mm (1.9 x 2.75 in.), Maximum : 297 x 432 mm (11.7 x 17 in.) |
| Thickness |
0.04 - 0.2 mm (1.6 - 7.9 mils)Note: 1 mil = 0.001 in. |
| Weight |
20 - 157 g/m2 (5 - 42 lbs.) |
| Feed Tray Capacity |
300 sheets: A6 to A3 size 80 g/m2 (21 lbs.) new paper150 sheets: less than 100 mm length paper 80 g/m2 (21 lbs.) new paper |
| Image Memory |
512MB |
| Supported Operating System |
Windows® XP SP3, Windows Vista® SP2, Windows® 7, Windows® 8, Windows® 10,Windows Server® 2003 SP2, Windows Server® 2003 R2 SP2, Windows Server® 2008 SP2 Windows Server® 2008 R2 SP1, Windows Server® 2012 |
| Interface |
USB3.0 interface (If the scanner is connected to a USB hub, it is not guaranteed to work.) |
| CPU |
Core 2 Duo 1.8GHz Memory 1GB USB2.0 or HigherCore i5 3.1GHz Memory 2GB USB3.0 (for Auto rescan/Auto preview) |
| Power Requirement |
100V : 100-127V, 50/60Hz, 1.5A200V : 220-240V, 50/60Hz, 0.8A |
| Power Consumption Scanning |
90 W or less / 1.5 A (100-120 V), Ready 30 W or less, Sleep 1.2 W or less, Power OFF 0.3 W or less |
| Operating Environment Temperature |
10 - 35°C (50 - 95°F) |
| Humidity |
20 - 80 % RH |
| Storage Environment Temperature |
0 - 40°C (32 - 104°F) |
| Humidity |
10 - 80 % RH |
| External Dimensions (W x D x H) |
468 x 444 x 344 mm (18.5 x 17.5 x 13.5 in.) |
| Weight |
17 kg (37.5 lbs.) |
| Warranty |
3 Tahun |
| Supported Driver |
ISIS driver software, TWAIN driver software |
| Type Scanner | ADF |
