| Spesifikasi | |
|---|---|
| Scanning Face |
Duplex |
| Scanning Method |
3-line Colour CCD, Selectable black and white background reference |
| Scanning Speed Binary / Colour A4 Size 200 Dpi |
Simplex Up to 70 ppm (Portrait), Up to 90 ppm (Landscape) |
| Scanning Speed Binary / Colour A4 Size 300 Dpi |
Simplex Up to 50 ppm (Portrait) Up to 60 ppm (Landscape) |
| Resolution |
600 dpi Optical Resolution 100 - 600 dpi (1 dpi step) |
| Detection |
Ultrasonic double feed detection (1 position), Stapled document detection |
| Compression |
JPEG (colour, greyscale) |
| Image Output |
Binary, Greyscale (8 bit), Colour, MultiStream™ output |
| Binary Mode Halftone |
Dither, Error diffusion |
| Image Control Executed By Driver Software Or Panasonic Image Capture Plus |
Dynamic Threshold, Automatic De-skewing, Automatic Crop, Automatic Binary/ Colour Distinction, Blank Page Removal, Double Exposure, Multi Colour Dropout, Smooth Background, Hole Removal, Border Removal, Noise Reduction, Detect File Separation Sheet and much more |
| Other Functions |
Length control, Barcode detection (ISIS), Patch code detection, Automatic separation, Control sheet, Long paper mode |
| Scanning Size |
305 mm x 2,540 mm (12.01 in. x 100 in.) |
| Documents Size (Adf) Minimum |
48 mm x 70 mm (1.9 in. x 2.75 in.) |
| Documents Size (Adf) Maximum |
297 mm x 432 mm (11.7 in. x 17 in.) |
| Documents Weight |
20 - 157 g/m2 (5 - 42 lbs.) |
| Documents Thickness |
0.04 - 0.2 mm (1.6 - 7.9 mils), Note: 1 mil = 0.001 in. |
| Hopper Capacity |
Up to 200 sheets (75 g/m2, 20 lbs.) New paper |
| Supported Operating System |
Windows® XP, Windows Vista®, Windows® 7 |
| Interface |
USB 2.0 |
| Power Requirement |
AC 100 - 240 V, 50/60 Hz |
| Power Consumption Maximum (Scanning) |
0.5 A (220 - 240 V), 1.0 A (100 - 120 V) |
| Power Consumption Minimum (Standby) |
0.2 A (220 - 240 V), 0.4 A (100 - 120 V) |
| Power Consumption Sleep Mode |
3.5 W or less (220 - 240 V, 100 - 120 V) |
| Operating Environment Temperature |
15°C - 30°C (59°F - 86°F) |
| Operating Environment Humidity |
20 - 80 % RH |
| Storage Environment Temperature |
0°C - 40°C (32°F - 104°F) |
| Storage Environment Humidity |
10 - 80 % RH |
| Product Dimension (W X D X H) |
468 mm x 444 mm x 339 mm (18.5 in. x 17.5 in. x 13.4 in.) |
| Weight |
18 kg (40 lbs.) |
| Accessories |
CD ROM : Device driver, Operation manual, Installation manual,Control data sheet, Image Capture Plus capture software,ISIS/TWAIN driver software, User utility software,Quick Scan Pro (DEMO)Installation manual, Power cord,Roller cleaning paper, Shading paper, USB cable (2.4 m) & Blower |
| Warranty |
3 Years Limited |
