| Spesifikasi | |
|---|---|
| Output format |
Color: 24-bit, Grayscale: 8-bit, Monochrome: 1-bit |
| Internal Video Processing |
4,096 levels (12-bit) |
| Image Processing Functions |
Multi image output, Automatic color detection, Blank page detection, Dynamic threshold (iDTC), Advanced DTC, SDTC, Error diffusion, De-Screen,Emphasis, Halftone, Dropout color (None / Red / Green / Blue / White / Saturation / Custom), sRGB output, Hole punch removal, Index tab cropping, Split image, De-Skew, Edge correction, Vertical streaks reduction, Cropping, Dither, Static threshold, Divide Long Page |
| Scanning Speed (A4 Landscape) |
ADF Simplex: 100 ppm, Duplex: 200 ipm (200 dpi / 300 dpi)Flatbed : 0.6 Seconds (200 dpi / 300 dpi) |
| Scanning Speed (A4 Portrait) |
ADF : Simplex: 80 ppm, Duplex: 160 ipm (200 dpi / 300 dpi)Flatbed : 0.9 Seconds (200 dpi / 300 dpi) |
| Paper chute capacity (A4 Landscape) |
300 Sheets (A4: 80 g/m² or 20 lb.) |
| Expected Daily Volume |
44,000 Sheets |
| Background Colors |
ADF : White / Black (switching with command available)Flatbed : White (switching to optional black available) |
| Document Size |
Minimum : 50.8 mm x 69 mm (2 in. x 2.72 in.)Maximum : 304.8 mm x 431.8 mm (12 in. x 17 in.)Long page scanning (Maximum) : 304.8 mm x 5,588 mm (12 in. x 220 in.)Flatbed (Maximum) : 304.8 mm x 457.2 mm (12 in. x 18 in. ) |
| Paper Weight (Thickness) |
Paper : 20 to 413 g/m² (5.3 to 110 lb.), A8 size: 128 to 209 g/m² (34 to 56 lb)Plastic Card : Up to 1.4 mm |
| Interface |
USB 3.1 Gen1 / USB 3.0 / USB 2.0 / USB 1.1 |
| Minimum PC Specification |
CPU: Intel Core i5 2400S @ 2.5Ghz |
| Power Requirements |
100 to 240 VAC ± 10 % |
| Power Consumption |
Operating: 64 W or less, Sleep mode: 1.7 W or less, Auto Standby(OFF) mode: Less than 0.35 W |
| Dimensions (WxDxH) |
706 mm x 500 mm x 345 mm (27.8 in. x 19.7 in. x 13.6 in.) |
| Weight |
35 kg (77.2 lb.) or less |
| Environmental Compatibility |
ENERGY STAR / RoHS |
| Operating Environment |
Temperature : 5²C to 35°C (41°F to 95°F)Relative Humidity : 20 % - 80 % (non-condensing) |
| Included Items |
ADF paper chute, AC cable, AC adapter, USB cable, Setup DVD-ROM |
| Included Software / Drivers |
PaperStream IP driver (TWAIN/TWAIN x64/ISIS), WIA Driver, PaperStream Capture, ScanSnap Manager for fi Series, Software Operation Panel, Error Recovery Guide, ABBYY FineReader for ScanSnap, Scanner Central Admin, 2D Barcode for PaperStream |
| Options |
Black Document Pad (fi-575BK), PaperStream Capture Pro |
| Supported Operating Systems |
Windows 10 (32-bit/64-bit),Windows 8.1 (32-bit/64-bit), Windows 7 (32-bit/64-bit), Windows Server 2019 (64-bit), Windows Server 2016 (64-bit), Windows Server 2012 R2 (64-bit), Windows Server 2012 (64-bit), Windows Server 2008 R2 (64-bit), Windows Server 2008 (32-bit/64-bit) |
| Warranty | 3 Years |
