| Spesifikasi | |
|---|---|
| Optical Resolution |
600 dpi |
| Output Resolution (Color / Grayscale / Monochrome) |
50 to 600 dpi (adjustable by 1 dpi increments) 1,200 dpi (driver) |
| Output Format |
Color: 24-bit, Grayscale: 8-bit, Monochrome: 1-bit |
| Background Colors |
White / Black (selectable |
| Document size |
Maximum : 304.8 x 431.8 mm (12 x 17 in.)Minimum : 50.8 x 69 mm (2 x 2.7 in.) (Portrait)Long Page Scanning : 5,588 mm (220 in.) |
| Paper Weight (Thickness) |
Paper : 20 to 413 g/m² (5.3 to 110 lb), Less than A8 size: 128 to 209 g/m² (34 to 56 lb)Plastic Card : up to 1.4 mm |
| Paper Chute Capacity (A4 Landscape) |
300 sheets (A4 80 g/m² or Letter 20 lb) |
| Typical Daily Duty Cycle |
30.000 sheets |
| Multifeed Detection |
Overlap detection (Ultrasonic sensor), Length detection |
| Paper Protection |
Warp detection, Sound detection (iSOP) |
| Interface |
USB 3.1 Gen 1 / USB 3.0 / USB 2.0 / USB 1.1 |
| Power Requirements |
AC 100 to 240 V ±10 % |
| Power Consumption |
Operating Mode : 64w or lessSleep Mode : 1.7W or lessAuto Stanby (off) mode : 0.35W or less |
| Operating environment |
Temperature: 5 to 35°C (41 to 95°F)Relative humidity: 20 to 80% (Non-condensing) |
| Environmental compliance |
ENERGY STAR and RoHS |
| Dimensions (W x D x H) |
236 x 432 x214mm (9.3 x 17.0 x 8.4 in.) |
| Weight |
11 kg (24 lb) |
| Supported Operating System |
Windows 10 (32-bit/64-bit), Windows 8.1 (32-bit/64-bit),Windows 7 (32-bit/64-bit), Windows Server 2016 (64-bit),Windows Server 2012 R2 (64-bit), Windows Server 2012(64-bit), Windows Server 2008 R2 (64-bit), Windows Server2008 (32-bit/64-bit) |
| Included Software / Drivers |
PaperStream IP driver (TWAIN/TWAIN x64/ISIS), PaperStream Capture, ScanSnap Manager for fi Series, Software Operation Panel, Error Recovery Guide, ABBYY FineReader for ScanSnap, Scanner Central Admin, 2D Barcode forPaperStream |
| Image Processing Functions |
Multi image output, Automatic color detection, Blank pagedetection, Dynamic threshold (iDTC), Advanced DTC, SDTC,Error diffusion, De-Screen, Emphasis, Halftone, Dropout color(None/Red/Green/Blue/White/Saturation/Custom), sRGBoutput, Hole punch removal, Index tab cropping, Split image,De-Skew, Edge correction, Vertical streaks reduction, Cropping,Dither, Static threshold, Divide Long Page |
| Included Items |
Stacker, ADF paper chute, AC cable, AC adapter,USB cable, Setup DVD-ROM |
| Warranty | 3 Years |
