| Spesifikasi | |
|---|---|
| Optical Resolution | 600 dpi |
| Output Resolution (Color/Grayscale/Monochrome) | 50 to 600 dpi (adjustable by 1 dpi increments) 1,200 dpi (driver) |
| Output Format | Color: 24-bit, Grayscale: 8-bit, Monochrome: 1-bit |
| Background Colors | ADF: White / Black (selectable)Flatbed: White (or optional black) |
| Document size | ADF Maximum : 304.8 x 431.8 mm (12 x 17 in.)ADF Minimum : 50.8 x 69 mm (2 x 2.7 in.) (Portrait)ADF Long page scanning : 5,588 mm (220 in.)Flatbed Maximum : 304.8 x 457.2 mm (12 x 18 in.) |
| Paper Weight (Thickness) | Paper : 20 to 413 g/m² (5.3 to 110 lb), Less than A8 size: 128 to 209 g/m² (34 to 56 lb)Plastic Card : up to 1.4 mm |
| ADF Capacity | 300 sheets (A4 80 g/m� or Letter 20 lb) |
| Expected Daily Volume | 33.000 sheets |
| Multifeed Detection | Overlap detection (Ultrasonic sensor), Length detection |
| Paper Protection | Lag detection, Sound detection (iSOP) |
| Interface | USB 3.1 Gen 1 / USB 2.0 / USB 1.1 |
| Power Requirements | AC 100 to 240 V ±10 % |
| Power Consumption | Operating Mode : 55w or lessSleep Mode : 1.7W or lessAuto Stanby (off) mode : 0.35W or less |
| Operating Environment | Temperature: 5 to 35°C (41 to 95°F)Relative humidity: 20 to 80% (Non-condensing) |
| Enviromental Compliance | ENERGY STAR and RoHS |
| Dimensions (W x D x H) | 700 x 500 x 345mm (27.8 x 19.7 x 13.6in.) |
| Weight | 35kg (77lb) |
| Supported Operating System | Windows 10 (32-bit/64-bit), Windows 8.1 (32-bit/64-bit),Windows 7 (32-bit/64-bit), Windows Server 2019 (64-bit),Windows Server 2016 (64-bit), Windows Server 2012 R2(64-bit), Windows Server 2012 (64-bit), Windows Server2008 R2 (64-bit), Windows Server 2008 (32-bit/64-bit) |
| Included Software / Drivers | PaperStream IP driver (TWAIN/TWAIN x64/ISIS), WIA Driver,PaperStream Capture, ScanSnap Manager for fi Series,Software Operation Panel, Error Recovery Guide, ABBYYFineReader for ScanSnap, Scanner Central Admin |
| Image Processing Functions | Multi image output, Automatic color detection, Blank pagedetection, Dynamic threshold (iDTC), Advanced DTC, SDTC,Error diffusion, Dither, De-Screen, Emphasis, Dropout color(None/Red/Green/Blue/White/Saturation/Custom), sRGBoutput, Hole punch removal, Index tab cropping, Split image,De-Skew, Edge correction, Vertical streaks reduction, Cropping,Static threshold, Divide long page |
| Included Items | Stacker, ADF paper chute, AC cable, AC adapter,USB cable, Setup DVD-ROM |
| Warranty | 3 Years |
