| Spesifikasi | |
|---|---|
| Scanner Type |
ADF (Automatic Document Feeder) |
| Scanning modes |
Simplex / Duplex, Color / Grayscale / Monochrome |
| Image Sensor Type |
Single line CMOS-CIS x 2 (Front x 1, Back x 1) |
| Light Source |
R, G, B LED x 2 (Front x 1,Back x 1) |
| Document size |
Maximum: A4 Portrait (210 x 297 mm) or Legal (8.5 x 14 in.) or 8.5 x 34 in. (215.9 x 863.6 mm) (long page scanning: 3,048 mm (120 in.))Minimum: A8 Portrait / Landscape (52 x 74 mm) |
| Paper weight (Thickness) |
Paper : 50 to 209 g/m2 (0.06 to 0.26 mm) A8 size: 127 to 209 g/m2 (0.15 to 0.26 mm),Plastic Card : ISO7810 ID-1 type compliant (0.76 mm or less, embossed plastic cards with total thickness of 1.24 mm or less) |
| Scanning speed (A4, Portrait) Color, Grayscale, Monochrome |
Simplex: 20 ppm (200 dpi / 300 dpi), Duplex: 40 ipm (200 dpi / 300 dpi) |
| Paper chute capacity (A4 Landscape) |
50 sheets (A4: 80g/m2or 20lb) |
| Expected daily volume |
3.000 sheets/day |
| Background colors |
White (Hardware, scanned background is gray) |
| Optical Resolution |
600 dpi |
| Output Resolution Color (24-bit), Grayscale (8-bit), Monochrome (1-bit) |
50 dpi to 600 dpi (adjustable by 1 dpi increments), 1,200 dpi (driver) (5) |
| Output format |
Color: 24-bit, Grayscale: 8-bit, Monochrome:1-bit |
| Internal video processing |
65,536 levels (16-bit) |
| Interface |
USB2.0 |
| Connector shape |
B type |
| Image processing function |
Auto color detection, Automatic page size detection, De-Skew, Multi-image, Blank page skip, Error diffusion, Dropout color (R, G, B, Saturation), Image emphasis, Advanced DTC, sRGB, Halftone, Smoothing, Split image, Vertical streaks reduction, Digital endorser, Edge correction, Dynamic threshold(iDTC) |
| Power requirement |
AC 100 V to 240 V 10% |
| Power consumption |
Operating: 18 W or less, Sleep mode: 1.6 W or less, Auto standby (OFF) mode: 0.4 W or less |
| Operating environment |
Temperature: 5 to 35 C (41 to 95 F),Relative humidity: 20 to 80% (Non-condensing) |
| Dimensions (W x D x H) |
298 mm x 135 mm x 133 mm (11.7 in. x 5.3 in. x 5.2 in.) |
| Weight |
2.5 kg |
| Included software / drivers |
PaperStream IP (TWAIN / TWAIN x64 / ISIS) for SP Series, PaperStream Capture Lite, Software Operation Panel, Error Recovery Guide, Presto! PageManager, ABBYY FineReader Sprint, Scanner Central Admin Agent |
| Environmental compliance |
ENERGY STAR and RoHS |
| Others |
Multifeed detection : Yes (Standard) ultrasonic multifeed detection sensor x 1, Long page scanning : 3.048 mm (120 in.) |
| Included items |
AC adapter, USB cable, Setup DVD-ROM |
| Supported operating systems |
Windows 10 (32-bit / 64-bit),Windows 8 / 8.1 (32-bit / 64-bit), Windows 7(32-bit / 64-bit), Windows Vista (32-bit / 64-bit), Windows Server 2012 R2(64-bit), Windows Server 2012 (32-bit / 64-bit), Windows Server 2008 R2 (64-bit), Windows Server 2008 (32-bit / 64-bit) |
| Warranty |
3 Years |
