| Image Sensor Type |
Charge coupled device (CCD) image sensor (x2) |
| Output Resolution Monochrome, Grayscale and Color |
50 to 600 dpi, 1200 dpi�(adjustable by 1 dpi increments) |
| Optical Resolution |
600 dpi |
| Output Format |
Color: 24-bit; Grayscale: 8-bit; Monochrome: 1-bit |
| AD Converter |
1,024 levels (10-bit) |
| ADF Capacity |
200 sheets (A4: 80 g/㎡ or 20 lb.) (Active loadable ADF) |
| Daily Duty Cycle |
15,000 Pages |
| Document Size ADF Minimum |
A8 (52 mm x 74 mm or 2 in. x 3 in.) |
| Document Size ADF Maximum |
A3 Portrait (297 mm x 420 mm or 11.7 in. x 16.5 in.) Double letter (279.4 mm x 431.8 mm or 11 in. x 17 in.) |
| Interfaces |
Ultra SCSI, USB2.0/USB1.1 (Selectable) |
| Letter/Landscape Mode Monochrome, Grayscale & Color 200 dpi |
Simplex : 90 ppmDuplex : 180 ipm |
| Letter/Landscape Mode Monochrome, Grayscale & Color 300 dpi |
Simplex : 80 ppmDuplex : 160 ipm |
| Letter/Portrait Mode Monochrome, Grayscale & Color 200 dpi |
Simplex : 70 ppmDuplex : 140 ipm |
| Letter/Portrait Mode Monochrome, Grayscale & Color 300 dpi |
Simplex : 60 ppmDuplex : 120 ipm |
| Power Requirements (auto-switching) |
AC 100 to 240 VAC, 50 / 60 Hz |
| Power Consumption |
Operating : 216 W, Sleep Mode : Less than 3 W, Less than 6.6 W (CGA), Auto Standby (Off) Mode : Less than 0.5 W |
| Operating Environment |
Temperature : 5 �C to 35 �C (41 �F to 95 �F) |
| Dimensions (HxWxD) |
300 mm x 641 mm x 432 mm (11.8 in. x 25.2 in. x 17 in.) |
| Weight |
17 kg (37.5 lb.) |
| Daily Duty Cycle |
Up to 15,000 documents per day |
| Features |
Automatic color detection, content-based rotation, intelligent blank page deletion, background saturation, advanced clarity, selectable background, onboard JPEG compression, dual control panels(3) |
| OS Support |
Windows 10 (32-bit/64-bit),�Windows 8 / 8.1 (32-bit/64-bit), Windows 7 (32-bit/64-bit), Windows Vista (32-bit/64-bit), Windows XP (32-bit/64-bit),�Windows Server 2016 (64-bit),�Windows Server 2012 R2 (64-bit), Windows Server 2012 (64-bit), Windows Server 2008 R2 (64-bit), Windows Server 2008 (32-bit/64-bit)� |
| Bundled Software |
PaperStream IP (TWAIN/ISIS) Driver, 2D Barcode for PaperStream, Software Operation Panel, Error Recovery Guide, PaperStream Capture, ScanSnap Manager for fi Series, ABBYY FineReader for ScanSnap, Scanner Central Admin Agent |
| Options |
Post-Imprinter, PaperStream Capture Pro |
| Others |
Multi-feed Detection : Yes, Ultrasonic double feed detection with Intelligent MultiFeed FunctionLong Paper Scanning : 3,048 mm (120 in.) |
| Warranty |
3 Years |
