| Image Sensor Type |
Color CCDs (Color Charge Coupled Device) |
| Light Source |
White LED Array |
| Optical Resolution |
600 dpi |
| Output Resolution Color (24-bit), Grayscale (8-bit), Monochrome |
50 to 600 dpi (adjustable by 1 dpi increments, 1,200 dpi(2)) |
| Output Color Depth |
Color: 24-bit, Grayscale: 8-bit, Monochrome: 1-bit |
| Internal Video Processing |
65,536 levels (16-bit) |
| Image Processing Function Hardware |
Dropout color (Red /Green /Blue), Deskew cropping |
| Image Processing Function Software |
Multi-image, Blank page skip, i-DTC, Advanced-DTC, Simplified-DTC, sRGB, Auto color, Deskew cropping, Hole punch removal, Tab cropping, Upper lower separation, Error diffusion, Dither, Moire removal, Image Emphasis, Color cleanup, Dropout color (R,G,B, None, white, Specified, Color Saturation), Edge repair, Vertical Streaks Reduction |
| Scanning Speed (A4, Portrait) Color, Grayscale, Monochrome |
ADF Simplex: 80 ppm, Duplex: 160 ipm (200 dpi / 300 dpi) Flatbed 1.7 seconds (200 dpi) |
| ADF Capacity |
80 Sheets (A4: 80 g/m� or 20 lb. ) |
| Expected Daily Volume |
11,000 Sheets |
| Document size ADF Minimum |
50.8 mm x 54 mm (2 in. x 2.13 in.) |
| Document size ADF Maximum |
216 mm x 355.6 mm (8.5 in. x 14 in.) |
| Document size Long Document |
216 mm x 5,588 mm (8.5 in. x 220 in.) (18.3 ft.) |
| Document size Flatbed |
216 mm x 297 mm (8.5 in. x 11.69 in.) |
| ADF Feeding Paper Weight (Thickness) Letter |
27 g/m� to 413 g/m� (7.2 lb. to 110 lb.) |
| ADF Feeding Paper Weight (Thickness) A8 sheets |
127 g/m� to 209 g/m� (34 lb. to 56 lb.) |
| ADF Feeding Paper Weight (Thickness) Card |
Up to 1.4 mm portrait and landscape feeding |
| Interface |
USB 3.0 / USB 2.0 / USB 1.1 (backward compatible) |
| Minimum PC Specification |
PaperStream IP i5 2.5 MHz Processor, 4 GB RAM |
| Power Requirements |
100 to 240 VAC �10 % |
| Power Consumption |
Operating mode: 43 W or less, Sleep mode: 1.8 W or less, Auto Standby (Off) mode: 0.35 W or less |
| Dimensions (WxDxH) |
300 mm x 577 mm x 234 mm (11.8 in. x 22.7 in. x 9.2 in.) |
| Weight |
8.8 kg (19.4 lb.) |
| Environmental Compatibility |
ENERGY STAR / RoHS |
| Operating Environment |
Temperature : 5�C to 35�C (41�F to 95�F), Relative Humidity : 20%-80% (non-condensing) |
| Inbox Contents |
ADF paper chute, AC cable, AC adapter, USB cable, Setup DVD-ROM, Getting Started Guide |
| Bundled Software |
PaperStream IP Driver (TWAIN/TWAIN x64/ISIS), WIA Driver, PaperStream Capture, ScanSnap Manager for fi Series, Software Operation Panel, Error Recovery Guide, ABBYY FineReader for ScanSnap, Scanner Central Admin, 2D Barcode for PaperStream |
| Options |
Carrier Sheet, Black Document Pad, PaperStream Capture Pro |
| OS Support |
Windows 10 (32-bit/64-bit),�Windows 8.1 (32-bit/64-bit), Windows 7 (32-bit/64-bit), Windows Server 2019 (64-bit), Windows Server 2016 (64-bit), Windows Server 2012 R2 (64-bit), Windows Server 2012 (64-bit), Windows Server 2008 R2 (64-bit), Windows Server 2008 (32-bit/64-bit), Linux (Ubuntu)(14)� |
| Feed Detection Features |
Ultrasonic Double Feed Detection Sensor, iSOP (Intelligent Sonic Paper Protection), Intelligent Multi-Feed Function (Manual Bypass) |
| Other Features |
Embossed Card Scanning Capability, Long Document Scanning, Scanner Central Admin management, USB 3.0 Support, iSOP (Intelligent Sonic Paper Protection), Automatic: Color Recognition, Paper-Size Detection, De-skew Correction |
| Warranty |
3 Years |
