CCD scanning technology

1200 dpi

48-bit/16-bit

1067 mm x 21.6 m, 914 mm x 26 m, 610 mm x 37.9 m, 305 mm x 75.76 m (using a color original at 200 dpi and TIFF file format)

Non-abrasive paper, vellum, Mylar, sepia, blueprints, plastic, film, plastic laminate, foam board, cardboard, newspaper, tracing paper. Varying condition documents: old, delicate, folded, creased, crumpled, damaged originals (no plywood, stone plates, metal plates or abrasive, dirty, rough, sharp edged, metal clamped, or burned surfaces or transparencies)

PDF, TIFF, JPEG, JPEG2000, DWF, CALS (B&W), multi-page PDF generation

File, email, USB, HDD, network folder, FTP, print

Standard, 500 GB

Dual Gigabit Ethernet (1000Base-T), Hi-Speed USB 3.0 certified

Input voltage (auto ranging): 100-240 V (±10%), 50/60 Hz, 5 A max

90 watts (scanning)80 watts (ready)< 3 watts (sleep)

5 to 40ºC

1530 x 930 x 1660 mm

71 kg

One-year limited hardware warranty
